Well I got all of the cables now. I went over to Walmart and got a Micro SD card 64G. I formatted the SD card with FAT. Then I went to http://hamvoip.org/RPi2/RPi2-3_V1.02beta_Allstar.img.zip downloaded the file and unzip the file and there was the Allstar.img and I right clicked and copied the file to the SD. I can’t get it to boot. Did I format the SD with the incorrect format? I go over to my computer and do IPCONFIG and there is only one ip being used.
Jerry Gainer, KC7GOL
14860 Chaparral Loop West
Peyton, Colorado 80831
Cell Phone: 719-660-0603
Aloha Jerry,
When you say “copied the file to the SD” I suspect that if I looked on that SD that I would find a file called RPi2-3_V1.02beta_Allstar.img
Copying it as a file is not what you need to do. Instead you need to use a disk imaging tool like win32diskimager to overwrite the SD card with the image.
Look at the instructions on https://hamvoip.org/#image
73,
John
WH6JV
···
On Tue, Nov 8, 2016 at 10:27 PM, Jerry Gainer jerald.gainer@gmail.com wrote:
Well I got all of the cables now. I went over to Walmart and got a Micro SD card 64G. I formatted the SD card with FAT. Then I went to http://hamvoip.org/RPi2/RPi2-3_V1.02beta_Allstar.img.zip downloaded the file and unzip the file and there was the Allstar.img and I right clicked and copied the file to the SD. I can’t get it to boot. Did I format the SD with the incorrect format? I go over to my computer and do IPCONFIG and there is only one ip being used.
Jerry Gainer, KC7GOL
14860 Chaparral Loop West
Peyton, Colorado 80831
Cell Phone: 719-660-0603
App_rpt-users mailing list
App_rpt-users@ohnosec.org
http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to the bottom of the page. Enter your email address and press the “Unsubscribe or edit options button”
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
Thanks very much. I have the system (I think working ) . It is asking for me to login in and I type login: root and password: root. Now it wants to know my node number but I don’t have one. I tried to get one but ---- well he said “All node requests have been fulfilled. You may want to try again.”
So I’m using TM-V71 for the radio. A cable comes out of the Data port to the DMK and then it connects to the RPi-3 B. It ask if I wanted to configure-----I was so happy I said yes. Then it ask for my node number. I’m thinking I don’t know how to ask for a node number. Boy! I’m sorry guys but I know I am so close.
Jerry Gainer, KC7GOL
14860 Chaparral Loop West
Peyton, Colorado 80831
Cell Phone: 719-660-0603
···
From: app_rpt-users-bounces@ohnosec.org [mailto:app_rpt-users-bounces@ohnosec.org] On Behalf Of John Vilburn
Sent: Wednesday, November 09, 2016 1:58 AM
To: app_rpt-users@ohnosec.org
Subject: Re: [App_rpt-users] what did I do incorrect
Aloha Jerry,
When you say “copied the file to the SD” I suspect that if I looked on that SD that I would find a file called RPi2-3_V1.02beta_Allstar.img
Copying it as a file is not what you need to do. Instead you need to use a disk imaging tool like win32diskimager to overwrite the SD card with the image.
Look at the instructions on https://hamvoip.org/#image
73,
John
WH6JV
On Tue, Nov 8, 2016 at 10:27 PM, Jerry Gainer jerald.gainer@gmail.com wrote:
Well I got all of the cables now. I went over to Walmart and got a Micro SD card 64G. I formatted the SD card with FAT. Then I went to http://hamvoip.org/RPi2/RPi2-3_V1.02beta_Allstar.img.zip downloaded the file and unzip the file and there was the Allstar.img and I right clicked and copied the file to the SD. I can’t get it to boot. Did I format the SD with the incorrect format? I go over to my computer and do IPCONFIG and there is only one ip being used.
Jerry Gainer, KC7GOL
14860 Chaparral Loop West
Peyton, Colorado 80831
Cell Phone: 719-660-0603
![G RANCH-1]()
App_rpt-users mailing list
App_rpt-users@ohnosec.org
http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to the bottom of the page. Enter your email address and press the “Unsubscribe or edit options button”
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
I had some flakiness with my Pi repeater which does a simplex radio and echolink transcoding - It would freeze from a function standpoint but be hot as heck to the touch. It has heat sinks. After playing with several Pi 3’s and heat sinks I think it was a flakey power supply.
However - what CPU core temps do you guys see? Mine run around high 40’s C or <120F range. Any info would be appreciated. Thanks!
Steven Donegan
KK6IVC General Class FCC License
FAA PP-ASEL Pilots License
Silver State Car #86
www.sscc.us
I typically see, without a cooling fan, temps of about 40 on my allstart pi and 35 on my mmdvm system. Small muffin fans drop the temps about 10-15 degrees.
···
–
Bryan
Sent from my iPhone 6S…No electrons were harmed in the sending of this message.
On Nov 9, 2016, at 12:38, Steven Donegan donegan@donegan.org wrote:
I had some flakiness with my Pi repeater which does a simplex radio and echolink transcoding - It would freeze from a function standpoint but be hot as heck to the touch. It has heat sinks. After playing with several Pi 3’s and heat sinks I think it was a flakey power supply.
However - what CPU core temps do you guys see? Mine run around high 40’s C or <120F range. Any info would be appreciated. Thanks!
Steven Donegan
KK6IVC General Class FCC License
FAA PP-ASEL Pilots License
Silver State Car #86
www.sscc.us
<mime-attachment.jpg>
