I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510 chrisviningre@gmail.com
Amateur Radio Operator: WS5B
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node number
Are you trying to get the pl tone to decode and encode?
If you want it to decode tones, you must be connected to vol/Sq hi (discriminator) signal on the master II for receive audio input. And you must set rxdemod to flat in the usbradio.conf file.
Also In usbradio.conf, set txmixa to voice and connect to the mic input.
set txmixb to tone and connect to the tx pl tone input on the exciter.
Recal all audio levels.
hope this helps.
cheers!
Jon VA3RQ
···
On 11/5/2016 5:19 PM, Chris Viningre wrote:
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
On Sat, Nov 5, 2016 at 3:40 PM, REDBUTTON_CTRL <jrorke@cogeco.ca> wrote:
Are you trying to get the pl tone to decode and encode?
If you want it to decode tones, you must be connected to vol/Sq hi
(discriminator) signal on the master II for receive audio input. And you
must set rxdemod to flat in the usbradio.conf file.
Also In usbradio.conf, set txmixa to voice and connect to the mic input.
set txmixb to tone and connect to the tx pl tone input on the exciter.
Recal all audio levels.
hope this helps.
cheers!
Jon VA3RQ
On 11/5/2016 5:19 PM, Chris Viningre wrote:
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to
the bottom of the page. Enter your email address and press the "Unsubscribe
or edit options button"
You do not need a password to unsubscribe, you can do it via email
confirmation. If you have trouble unsubscribing, please send a message to
the list detailing the problem.
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to
the bottom of the page. Enter your email address and press the "Unsubscribe
or edit options button"
You do not need a password to unsubscribe, you can do it via email
confirmation. If you have trouble unsubscribing, please send a message to
the list detailing the problem.
Ok make sure you have the vol/Sq hi line connected to pin 21 "mic in " on the URI. and ground to any of the ground pins on the URI.
If you are not sure you are connected to vol/SQ hi on the mastr II, you can usually find it on the hi side of the Squelch pot on the tray that folds down (if you have the station).
From below it looks like there is no receive audio connected to the URI.
Jon RQ
···
On 11/5/2016 7:38 PM, Chris Viningre wrote:
I tried the settings and still no tone squelch. This is what I get
when I do a radio-tune-menu. I dont know if this would help.
Please enter your selection now: 4
INFO: RX CTCSS ADJUST START.
target=2400 tolerance=100
tries=0, setting=1.000000, meas=0
tries=1, setting=8.000000, meas=0
tries=2, setting=8.000000, meas=0
tries=3, setting=8.000000, meas=0
tries=4, setting=8.000000, meas=0
tries=5, setting=8.000000, meas=0
tries=6, setting=8.000000, meas=0
tries=7, setting=8.000000, meas=0
tries=8, setting=8.000000, meas=0
tries=9, setting=8.000000, meas=0
tries=10, setting=8.000000, meas=0
tries=11, setting=8.000000, meas=0
DONE tries=12, setting=8.000000, meas=0.00
ERROR: RX CTCSS GAIN ADJUST FAILED.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
chrisviningre@gmail.com
Amateur Radio Operator: WS5B WS5B - Callsign Lookup by QRZ Ham Radio Chris Viningre | ReverbNation
On Sat, Nov 5, 2016 at 3:40 PM, REDBUTTON_CTRL<jrorke@cogeco.ca> wrote:
Are you trying to get the pl tone to decode and encode?
If you want it to decode tones, you must be connected to vol/Sq hi
(discriminator) signal on the master II for receive audio input. And you
must set rxdemod to flat in the usbradio.conf file.
Also In usbradio.conf, set txmixa to voice and connect to the mic input.
set txmixb to tone and connect to the tx pl tone input on the exciter.
Recal all audio levels.
hope this helps.
cheers!
Jon VA3RQ
On 11/5/2016 5:19 PM, Chris Viningre wrote:
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to
the bottom of the page. Enter your email address and press the "Unsubscribe
or edit options button"
You do not need a password to unsubscribe, you can do it via email
confirmation. If you have trouble unsubscribing, please send a message to
the list detailing the problem.
To unsubscribe from this list please visit http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users and scroll down to
the bottom of the page. Enter your email address and press the "Unsubscribe
or edit options button"
You do not need a password to unsubscribe, you can do it via email
confirmation. If you have trouble unsubscribing, please send a message to
the list detailing the problem.
carrierfrom=dsp ; Carrier Detect Source ; Options - no,usb,usbinvert,dsp,vox ; no - no carrier detection at all ; usb - via USB radio adapter COR connection ; usbinvert - same as above but inverted polarity. ; dsp - from RX noise using dsp methods ; vox - voice activated via RX audio
From: Chris Viningre Sent: Sat Nov 05 17:19:25 EDT 2016 To:app_rpt-users@ohnosec.org Subject: [App_rpt-users] No PL Tone
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
chrisviningre@gmail.com
Amateur Radio Operator: WS5B
[https://www.qrz.com/db/ws5b](https://www.qrz.com/db/ws5b)
[http://www.reverbnation.com/chrisviningre](http://www.reverbnation.com/chrisviningre)
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node
number
rxchannel=Radio/usb43934
duplex=2
erxgain=-3
etxgain=3
;controlstates=controlstates
scheduler=schedule43934
morse=morse43934
macro=macro43934
functions=functions43934
phone_functions=functions43934
link_functions=functions43934
telemetry=telemetry
wait_times=wait-times
context = radio
callerid = "Repeater" <0000000000>
idrecording = |iWS5B
accountcode=RADIO
hangtime=1000
;
; Usbradio channel driver Configuration
File
;
[general]
[usb43934]
hdwtype=0
rxboost=1
txboost=1
rxctcssrelax=1
txctcssdefault=100.0
rxctcssfreqs=100.0
txctcssfreqs=100.0
;rxctcssoverride=0
carrierfrom=usb
ctcssfrom=usb
rxdemod=speaker
txprelim=no
txlimonly=no
txtoctype=no
txmixa=composite
txmixb=no
invertptt=0
duplex=1
rxondelay=0
rxnoisefiltype=0
eeprom=0
---
App_rpt-users mailing list
App_rpt-users@ohnosec.org
[http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users](http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users)
To unsubscribe from this list please visit [http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users](http://ohnosec.org/cgi-bin/mailman/listinfo/app_rpt-users) and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options
button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
</details>
I may have been unclear on the problem. I am not getting any tone
squelch. The repeater is working fine other then that. I have
tried these settings and still no luck. Thanks for all the help.
no,usb,usbinvert,dsp,vox ; no - no carrier detection at all ;
usb - via USB radio adapter COR connection ; usbinvert - same as
above but inverted polarity. ; dsp - from RX noise using dsp
methods ; vox - voice activated via RX audio
From: Chris Viningre Sent: Sat Nov 05 17:19:25 EDT 2016 To:
[App_rpt-users] No PL Tone
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
Amateur Radio Operator: WS5B
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node
number
rxchannel=Radio/usb43934
duplex=2
erxgain=-3
etxgain=3
;controlstates=controlstates
scheduler=schedule43934
morse=morse43934
macro=macro43934
functions=functions43934
phone_functions=functions43934
link_functions=functions43934
telemetry=telemetry
wait_times=wait-times
context = radio
callerid = "Repeater" <0000000000>
idrecording = |iWS5B
accountcode=RADIO
hangtime=1000
;
; Usbradio channel driver Configuration
File
;
[general]
[usb43934]
hdwtype=0
rxboost=1
txboost=1
rxctcssrelax=1
txctcssdefault=100.0
rxctcssfreqs=100.0
txctcssfreqs=100.0
;rxctcssoverride=0
carrierfrom=usb
ctcssfrom=usb
rxdemod=speaker
txprelim=no
txlimonly=no
txtoctype=no
txmixa=composite
txmixb=no
invertptt=0
duplex=1
rxondelay=0
rxnoisefiltype=0
eeprom=0
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options
button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
I may have been unclear on the problem. I can not get the
repeater to tone squelch. It is always open. The repeater is
working fine other then that. I have tried these settings and
still no luck. Thanks for all the help.
no,usb,usbinvert,dsp,vox ; no - no carrier detection at all ;
usb - via USB radio adapter COR connection ; usbinvert - same as
above but inverted polarity. ; dsp - from RX noise using dsp
methods ; vox - voice activated via RX audio
From: Chris Viningre Sent: Sat Nov 05 17:19:25 EDT 2016 To:
[App_rpt-users] No PL Tone
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
Amateur Radio Operator: WS5B
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node
number
rxchannel=Radio/usb43934
duplex=2
erxgain=-3
etxgain=3
;controlstates=controlstates
scheduler=schedule43934
morse=morse43934
macro=macro43934
functions=functions43934
phone_functions=functions43934
link_functions=functions43934
telemetry=telemetry
wait_times=wait-times
context = radio
callerid = "Repeater" <0000000000>
idrecording = |iWS5B
accountcode=RADIO
hangtime=1000
;
; Usbradio channel driver Configuration
File
;
[general]
[usb43934]
hdwtype=0
rxboost=1
txboost=1
rxctcssrelax=1
txctcssdefault=100.0
rxctcssfreqs=100.0
txctcssfreqs=100.0
;rxctcssoverride=0
carrierfrom=usb
ctcssfrom=usb
rxdemod=speaker
txprelim=no
txlimonly=no
txtoctype=no
txmixa=composite
txmixb=no
invertptt=0
duplex=1
rxondelay=0
rxnoisefiltype=0
eeprom=0
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options
button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
Personally I wouldn’t bother with using the tone boards in the MII.
On both of mine, I just pulled VOL/SQL HI from the backplane. Then let the usbradio DSP do it all.
On the MIIe (direct FM exciter) I was able to feed both CG and voice into the CG input of the exciter. Measured it to be flat to 8 KC. Then let usbradio do the pre-emphasis, CG encode/decode, and de-emphasis.
On the regular MII (phase modulated exciter), again all DSP. Voice into the exciter mic input, CG encode to the CG input. With the exciter doing the pre-emphasis.
no,usb,usbinvert,dsp,vox ; no - no carrier detection at all ;
usb - via USB radio adapter COR connection ; usbinvert - same as
above but inverted polarity. ; dsp - from RX noise using dsp
methods ; vox - voice activated via RX audio
From: Chris Viningre Sent: Sat Nov 05 17:19:25 EDT 2016 To:
[App_rpt-users] No PL Tone
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
Amateur Radio Operator: WS5B
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node
number
rxchannel=Radio/usb43934
duplex=2
erxgain=-3
etxgain=3
;controlstates=controlstates
scheduler=schedule43934
morse=morse43934
macro=macro43934
functions=functions43934
phone_functions=functions43934
link_functions=functions43934
telemetry=telemetry
wait_times=wait-times
context = radio
callerid = "Repeater" <0000000000>
idrecording = |iWS5B
accountcode=RADIO
hangtime=1000
;
; Usbradio channel driver Configuration
File
;
[general]
[usb43934]
hdwtype=0
rxboost=1
txboost=1
rxctcssrelax=1
txctcssdefault=100.0
rxctcssfreqs=100.0
txctcssfreqs=100.0
;rxctcssoverride=0
carrierfrom=usb
ctcssfrom=usb
rxdemod=speaker
txprelim=no
txlimonly=no
txtoctype=no
txmixa=composite
txmixb=no
invertptt=0
duplex=1
rxondelay=0
rxnoisefiltype=0
eeprom=0
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options
button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
no,usb,usbinvert,dsp,vox ; no - no carrier detection at all ;
usb - via USB radio adapter COR connection ; usbinvert - same
as above but inverted polarity. ; dsp - from RX noise using
dsp methods ; vox - voice activated via RX audio
From:
Chris Viningre Sent: Sat Nov 05 17:19:25 EDT 2016 To:
[App_rpt-users] No PL Tone
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
Amateur Radio Operator: WS5B
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node
number
rxchannel=Radio/usb43934
duplex=2
erxgain=-3
etxgain=3
;controlstates=controlstates
scheduler=schedule43934
morse=morse43934
macro=macro43934
functions=functions43934
phone_functions=functions43934
link_functions=functions43934
telemetry=telemetry
wait_times=wait-times
context = radio
callerid = "Repeater" <0000000000>
idrecording = |iWS5B
accountcode=RADIO
hangtime=1000
;
; Usbradio channel driver Configuration
File
;
[general]
[usb43934]
hdwtype=0
rxboost=1
txboost=1
rxctcssrelax=1
txctcssdefault=100.0
rxctcssfreqs=100.0
txctcssfreqs=100.0
;rxctcssoverride=0
carrierfrom=usb
ctcssfrom=usb
rxdemod=speaker
txprelim=no
txlimonly=no
txtoctype=no
txmixa=composite
txmixb=no
invertptt=0
duplex=1
rxondelay=0
rxnoisefiltype=0
eeprom=0
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options
button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
_______________________________________________
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
That was it. Thank you to everyone that tought this old dog some new
tricks. Y’all are great!
Chris
···
On 11/06/2016 05:22 PM, REDBUTTON_CTRL
wrote:
Good catch by Robert.
I think you have to have both carrierfrom and ctcssfrom set to dsp
in usbradio.conf. for the tone decoding to work.
On 11/6/2016 6:22 PM, Bob Poff wrote:
Personally I wouldn't bother with using the tone boards in
the MII.
On both of mine, I just pulled VOL/SQL HI from the
backplane. Then let the usbradio DSP do it all.
On the MIIe (direct FM exciter) I was able to feed both CG
and voice into the CG input of the exciter. Measured it to be
flat to 8 KC. Then let usbradio do the pre-emphasis, CG
encode/decode, and de-emphasis.
On the regular MII (phase modulated exciter), again all
DSP. Voice into the exciter mic input, CG encode to the CG
input. With the exciter doing the pre-emphasis.
Robert A. Poff
Loganville, Pa
From:
Chris Viningre Sent: Sun Nov 06 16:19:11 EST 2016 To: Bob Poff Cc:
Re: [App_rpt-users] No PL Tone
I may have been unclear on the problem. I can not get the
repeater to tone squelch. It is always open. The repeater is
working fine other then that. I have tried these settings and
still no luck. Thanks for all the help.
Chris
_______________________________________________
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
no,usb,usbinvert,dsp,vox ; no - no carrier detection at all
; usb - via USB radio adapter COR connection ; usbinvert -
same as above but inverted polarity. ; dsp - from RX noise
using dsp methods ; vox - voice activated via RX audio
From:
Chris Viningre Sent: Sat Nov 05 17:19:25 EDT 2016 To:
[App_rpt-users] No PL Tone
I am trying to get the PL tone of 100.0 hz to work on my GE Mastr II
repeater. I'm using a URI interface on a laptop running Dail software.
Everything is working other than the tones. Here is my rpt.conf and
usbradio.conf. Thanks for any help.
Chris Viningre
70 W. Roadrunner
Salt Flat, Texas 79847
C:(915) 504-1510
Amateur Radio Operator: WS5B
Radio Repeater configuration file (for use with app_rpt)
;
;
; Your Repeater
;
[43934] ; Change this to your assigned node
number
rxchannel=Radio/usb43934
duplex=2
erxgain=-3
etxgain=3
;controlstates=controlstates
scheduler=schedule43934
morse=morse43934
macro=macro43934
functions=functions43934
phone_functions=functions43934
link_functions=functions43934
telemetry=telemetry
wait_times=wait-times
context = radio
callerid = "Repeater" <0000000000>
idrecording = |iWS5B
accountcode=RADIO
hangtime=1000
;
; Usbradio channel driver Configuration
File
;
[general]
[usb43934]
hdwtype=0
rxboost=1
txboost=1
rxctcssrelax=1
txctcssdefault=100.0
rxctcssfreqs=100.0
txctcssfreqs=100.0
;rxctcssoverride=0
carrierfrom=usb
ctcssfrom=usb
rxdemod=speaker
txprelim=no
txlimonly=no
txtoctype=no
txmixa=composite
txmixb=no
invertptt=0
duplex=1
rxondelay=0
rxnoisefiltype=0
eeprom=0
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options
button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
_______________________________________________
App_rpt-users mailing list
To unsubscribe from this list please visit and scroll down to the bottom of the page. Enter your email address and press the "Unsubscribe or edit options button"
You do not need a password to unsubscribe, you can do it via email confirmation. If you have trouble unsubscribing, please send a message to the list detailing the problem.
